HPC 121x8" SST Torpedo Linear Interlink Pan Fire Pit Insert TOR-121X8SSEI-L-LP/24VAC
The beautiful SST Torpedo Linear Interlink Pan Fire Pit Insert will make a visual impact on any build. Its design allows the control box of the remote electronic ignition inserts to be inside the match lit ignition system valve. This gives the flexibility for placing the fire pit at ground level. All models are CSA certified and burners are covered with lifetime warranty. You'll have SST Torpedo burner, the HPC’s newly designed nozzle which creates the biggest flame and experience more like a bonfire or standard burner.
HPC SST Torpedo Fire Pit Insert Features and Specifications
SST Torpedo Burners
The commercial-grade SST Torpedo burner, available in Penta, Linear and H configurations; is the HPC's newly designed nozzle which creates the biggest flame on the market. The SST Torpedo Burners yield an enhanced bonfire like aesthetic. This is a great addition to HPC's product offerings, providing customers with an array of flame options.
HPC FIRE ONE APP
HPC Fire Inspired’s new augmented reality app lets you select options, scan your area, and place our products in your design. Just select, scan & see the design in real time.
Download it today on your Apple, Droid, or Google phone today by searching “HPC One App”. Or go to hpcfire.com/one-app today.
- HPC AR: The Augmented Reality app allows you to see finished products in real-time to make sure the aesthetic and look are exactly what you desire. HPC’s AR App is a big hit with contractors and designers alike and truely enhances the customer experience.
- HITS: The HITS app is a building instruction, tools needed, clearance given, troubleshooting beast for anyone that has an HPC Fire feature. Simply choose the product you are working with and let the app do the rest. It starts with tools and clearances needed and goes into the step-by-step instructions of how to properly install any HPC Fire appliance.
- HPC FIRE: The HPC FIRE app allows you to control the electronic ignition-High- Low models. The HPC FIRE app does a lot more than just light your fire, it allows you to change the flame height from high to low and achieve the ambiance you desire. As added safety precautions the app offers password protected parental safety controls.
Features
- Burner Type: Torpedo
- Electronic Ignition
- Fully Assembled- ready to install. Control components are protected within the valve box.
- Start via wall switch or remote control; Auto re-light if flame is lost.
- Ignition is complete using a robust and reliable Hot Surface igniter.
- On/Off models: Use with optional wall switch, Remote Control or your whole house system
- High/Low Flame Control Models: Adjust high setting to low setting- ~45% turndown (Remote Control included). Not for use with your whole house system.
- 120vac: Standard outdoor grounded power cord- simply plug into GFCI outlet.
- 24vac Option: Typically used with lower voltage requirements. Requires HPC/SEBCO 24vac, 100W Power Supply
- Natural Gas or Liquid Propane.
- Internal temperature monitoring with overheat auto shutoff.
- CSA Certified in US & Canada to ANSI Z21.97-2017 / CSA 2.41-2014 requirements. (This new EI system already meets upcoming 2020 ANSI requirements).
- Optional Controls: On/Off Remote, Timers, Power Supplies and an Emergency Shutoff.
- Smart device App available on Hi/Lo Models only
Specifications
- Weight: 225lbs
- Skid Dimensions = 124x30x32"
- Max BTU 250,000
- Nozzle BTU 300,000
How It Works
Start-Up: This is done by the use of a wall switch or remote control. When the ON command is received, the system completes initial safety checks then starts the flow of pilot gas. After 5 seconds the hot surface igniter glows igniting the pilot flame. When the system confirms the pilot flame is present, the main burner gas will flow ignited by the pilot flame.
Operation: While enjoying the ambiance of your fire pit, the system is at work monitoring flame status, internal temperatures/voltages, and other safety parameters. If flame loss does occur, the system will turn off all gas flow, and then restart by automatically commencing the Start sequence.
On/Off Models: Includes the convenience and safety features- optional remote control available.
Bluetooth High / Low Flame Control Models: This option includes a smart remote and App via smart device control with 2-way communication with the fire pit. Remote allows flame height control while receiving information from the fire pit to advise the user of fire pit status (flashing LED).
Shut Down: To turn OFF the fire pit simply use a wall switch, remote control, or whole house system.
So what are you waiting for? Add the HPC 121x8" SST Torpedo Linear Interlink Pan Fire Pit Insert to your cart and upgrade your outdoor garden.
