Description
HPC 96" SST Torpedo Burner Linear Trough Fire Pit Insert TOR-96SSEI-TRGH-HI/LO-LP/24VAC
The HPC - 96" Linear Trough Fire Pit Insert is a fully assembled, commercial grade, certified insert that is perfect for your fire pit needs. This insert features a EI & Push Button of 250k BTU, a 96" burner, and is made of #304, 18 gauge stainless steel. The spun design of this insert adds rigidity and the welded gas fitting provides strength, while the weep holes allow for drainage. This product is perfect for those who want a reliable and easy-to-use fire pit insert that will provide years of enjoyment.
HPC SST Torpedo Linear Trough Fire Pit Insert Features and Specifications
Features
- Burner: Torpedo
- Made of #304, 18 gauge Stainless Steel
- The spun design adds rigidity
- Welded gas fitting for strength
- Weep holes for drainage
- Fully Assembled- ready to install. Control components are protected within valve box.
- Start via wall switch or remote control; Auto re-light if flame is lost.
- Ignition is complete using a robust and reliable Hot Surface igniter.
- On/Off models: Use with optional wall switch, Remote Control or your whole house system
- High/Low Flame Control Models: Adjust high setting to low setting- ~45% turndown (Remote Control included). Not for use with your whole house system.
- 120vac: Standard outdoor grounded power cord- simply plug into GFCI outlet.
-
24vac Option: Typically used with lower voltage requirements. Requires HPC/ SEBCO 24vac, 100W Power Supply
- Natural Gas or Liquid Propane.
- Internal temperature monitoring with overheat auto shutoff.
Specifications
- Weight: 140lbs
- Dimensions L-96" x W-7.9" x D- 2.5"
- Skid Dimensions 100" x 30" x 25"
- Max BTU:
[Electronic Ignition] 200k
[Push Button/Flame Sense] 140k - Nozzle BTU:
[Electronic Ignition] 250k
[Push Button/Flame Sense] 250k
How It Works
Start Up: This is done by use of a wall switch or remote control. When the ON command is received, the system completes initial safety checks then starts flow of pilot gas. After 5 seconds the hot surface igniter glows igniting the pilot flame. When the system confirms the pilot flame is present, the main burner will be ignited by the pilot flame.
Operation: While enjoying the ambiance of your fire pit, the system is at work monitoring flame status, internal temperatures / voltages and other safety parameters. If flame loss does occur, the system will turn off all gas flow, and then restart by automatically commencing the start sequence.
- On/Off Models: Includes the convenience and safety features- optional remote control available
- Bluetooth High / Low Flame Control Models: This option includes a smart remote as well as a smart app enabling 2-way communication with the fire pit. Remote allows
flame height control while receiving information from fire pit to advise user of fire pit status (flashing LED).
Shut Down: To turn OFF the fire pit simply use wall switch, remote control or whole house system.
So what are you waiting for? Add the HPC 96" Linear Trough Electronic Ignition ON-OFF / 24VAC Fire Pit to your cart and upgrade your outdoor garden.
